800x480 LVDS High Brightness LCD Display TFT 5.0 Inch Industrial
100 Nits
KD050HWV18ES V1.0 SPEC(1).pdf
KADI 5.0inch 800*480 display for medical monitors
KD050HWV18ES is a 5.0-inch a-Si TFT-LCD liquid crystal module
product launched by KADI. It is equipped with WLED backlight,
including LED driver backlight drive, no touch.The service life of
the light source is 30K hours, including LED driver.This model is
recommended for industrial, car display, medical imaging and other
products. This product will be mass-produced in Q2 2020, and the
current production status is in mass production.
| Feature | Spec |
Characteristics | Size | 5 inch |
| Resolution | 800(horizontal)*480(Vertical) |
| Interface | RGB-24bit |
| Connect type | Connector |
| Display Colors | 16M |
| Technology type | a-Si |
| Pixel pitch (mm) | 0.135*0.135 |
| Pixel Configuration | R.G.B.-Stripe |
| Display Mode | Normally Black |
| LCD Driver IC | ST7262 |
| Viewing Direction | Full view |
Mechanical | LCM (W x H x D) (mm) | 120.7*75.80*2.95 |
| Active Area(mm) | 108 x 64.80 |
| Weight (g) | TBD |
| LED Numbers | 14 LEDs |
Note 1: Requirements on Environmental Protection: RoHs
Note 2: LCM weight tolerance: +/- 5%
Actual Product Applications
Bar type LCD display, also known as stretched TFT LCD display, is
mainly used in strip TFT LCD screens with special fit size. The
mainstream aspect ratio of the TFT LCD panel is 4:3 or 16:9. But
for some applications, bar type shape of the display panel would be
much better than the current mainstream 4:3 or 16:9 to display the
required information. It is especially suitable for server system,
audio system and advertising display, security equipment,
Industrial equipment, medical equipment, drone controls. Full-color
TFT wide-screen displays (Bar Type TFT) is widely used on the
supermarket.
FAQ
- Q: Products are in stock? How long can you deliver?
- A: Samples available in stock will be sent within 3 days; Small
batch delivery takes 2-3 weeks; Large batch delivery takes 5-6
weeks
- Q: What is the minimum order quantity?
- A: All our products have MOQ requirements, please contact our
salesman for detailed information.
- Q: How long is the warranty and service of the product?
- A: Generally the warranty period is one year.
- Q: What kind of packaging? The transport process will not be
damaged?
- A: Our products are divided into two categories, small-medium size
use knife card isolation packaging, large size screens are used in
aircraft box packaging, all packages are protected by outer box and
strapping to ensure the safety of the material transportation.
- Q: Payment Terms?
- A: For samples, Paypal can be accepted. But for mass production,
credit card or T/T full payment before produce and delivery is
needed.
